Vibration Control and Stability Improvement in Machine Tool Machining

I. Types and Causes of Machining Vibration

1. Main Types of Vibration

• Forced vibration: Caused by external periodic excitation, such as unbalanced spindles, gear meshing gaps, and motor rotor eccentricity. Its vibration frequency is consistent with the frequency of the excitation source, and the amplitude increases with the intensity of the excitation.

• Self-excited vibration: Sustained vibration formed by the self-feedback of the cutting process, related to the cutting force and the dynamic characteristics of the tool-workpiece elastic system. Its vibration frequency is close to the natural frequency of the system, and once generated, it will intensify with the extension of cutting time, which is a major hidden danger in high-speed precision machining.

2. Key Influencing Factors

• System rigidity: When the rigidity of the elastic system composed of the machine tool bed, spindle, tool, and workpiece is insufficient, it is prone to deformation and vibration under the action of cutting force. Rigidity weaknesses usually occur in links such as excessive tool overhang and unstable workpiece clamping.

• Cutting parameters: Mismatch of cutting speed, feed rate, and cutting depth may induce resonance. For example, at a certain critical speed, the fluctuation frequency of cutting force coincides with the natural frequency of the system, leading to a sudden increase in chatter.

• Tool and workpiece characteristics: Dull tool edges will increase cutting resistance and intensify vibration; in the cutting process of high-hardness and high-toughness materials, the material deformation resistance is large, making it more likely to cause vibration.

II. Vibration Detection and Evaluation Methods

1. Vibration Signal Acquisition Methods

• Sensor detection: Vibration acceleration signals are collected by acceleration sensors (installed on the spindle or workpiece table), and amplitude changes are recorded by displacement sensors. The sampling frequency must cover the vibration frequency range that may occur during machining (usually ≥2kHz).

• Indirect monitoring method: Vibration intensity is judged indirectly by analyzing changes in cutting force (piezoelectric dynamometer), acoustic emission signals (acoustic sensors), or motor current fluctuations, which is suitable for scenarios where it is inconvenient to install vibration sensors.

2. Vibration Evaluation Indicators

• Amplitude and frequency: Amplitude directly reflects vibration intensity, and in precision machining, the amplitude is usually required to be ≤0.01mm; frequency distribution can help locate the vibration source (for example, the vibration frequency of spindle bearings is concentrated in 100-500Hz, and tool chatter is mostly in 500-2000Hz).

• Vibration acceleration level: Vibration energy is quantified by decibels (dB), and there are clear thresholds for different machining scenarios (for example, mold finishing requires ≤60dB, and heavy cutting can be relaxed to 75dB).

• Surface quality correlation: Surface waviness and abnormal roughness caused by vibration are intuitive evaluation bases. For example, chatter will form periodic patterns on the workpiece surface, and the spacing is directly related to vibration frequency and feed speed.

III. Core Strategies for Vibration Control

1. Improvement of System Rigidity

• Structural optimization: Enhance the overall rigidity by increasing the wall thickness of the machine tool bed and adopting a box-type rib structure; the spindle system adopts a short nose design to reduce overhang length and deflection.

• Strengthening of connection links: The 配合 between the tool and the spindle adopts short taper shanks such as HSK and CAPTO, which improves connection rigidity through interference fit; the workpiece clamping adopts multi-point positioning and auxiliary support to avoid the "tool deflection" phenomenon during thin-walled part machining.

• Material selection: The bed is made of high-damping cast iron (such as Meehanite cast iron), whose damping coefficient is 2-3 times that of ordinary cast iron, which can effectively absorb vibration energy.

2. Adaptive Adjustment of Cutting Parameters

• Avoiding resonance intervals: Determine the critical cutting speed through pre-tests, and select parameters higher or lower than this speed in actual machining. For example, in a certain aluminum alloy milling, the critical speed is 1200r/min, which can be adjusted to 1000r/min or 1500r/min to avoid resonance.

• Optimizing feed rate and cutting depth: On the premise of ensuring efficiency, appropriately reduce the cutting depth to reduce cutting force, or change the fluctuation frequency of cutting force by increasing the feed rate to break the feedback cycle of chatter generation.

3. Application of Vibration Suppression Technologies

• Passive suppression: Use dampers (such as viscoelastic damping blocks, squeeze film dampers) to attenuate vibration. The tool system can be equipped with a power tool holder damping device to reduce high-frequency vibration transmission.

• Active control: Generate reverse force to offset vibration by real-time monitoring of vibration signals through actuators (such as piezoelectric ceramics). The response time needs to be controlled at the millisecond level, which is suitable for high-precision machining centers.

IV. Practical Points for Vibration Management

1. Precautionary Measures

• Process planning stage: Determine the natural frequency of the system through modal analysis (finite element simulation), and avoid resonance frequency bands in the design of cutting parameters.

• Equipment selection considerations: Give priority to machine tools with high rigidity structures (such as integral beds) and spindles with high dynamic balance grades (usually requiring G0.4 or higher) to reduce vibration sources.

2. Process Control Methods

• Real-time monitoring and adjustment: Integrate vibration monitoring modules into automated production lines. When the vibration value exceeds the threshold, automatically adjust cutting parameters (such as reducing feed speed) or pause machining to avoid quality accidents.

• Tool status management: Establish a tool wear monitoring mechanism, replace dull tools in time, maintain a stable cutting force state, and reduce vibration caused by tool factors.

3. Long-Term Maintenance Strategies

• Regular rigidity verification: Detect the dynamic rigidity of each axis of the machine tool through a laser interferometer, at least once a year, and timely find the rigidity decline caused by guide rail wear and increased screw clearance.

• Foundation and installation maintenance: Check the tightness of the machine tool's anchor bolts to ensure uniform settlement of the installation foundation; when restarting after long-term shutdown, preheating operation is required, and high-precision machining is performed after the system reaches thermal equilibrium to reduce vibration caused by thermal deformation.
